Setup & Maintenance

Need help getting started? This step-by-step guide makes setting up your chiller simple and fast — available in both video and written form.

Water Chiller Setup and Operation Guide

In this video, we’ll walk you through how to use and set up the screen functions on your Cold Plunge Chiller.



1.🔌Power On the Chiller

✅ Plug in the chiller.

✅ Press and hold the power button .

✅ Once on, the screen will display the current water temperature.

💤 If the display shows “OFF”, the unit is in standby mode.



2. 🌡 Set Target Temperature to 45°F (Maintain Between 45°F–50°F)

• Use the up and down buttons to set the temperature to 45°F.

• Press and hold the up and down buttons together to enter F01 mode, then set it to 5°F.

• Press the power button to confirm the setting.

• This setup ensures the water stays between 45°F and 50°F.



3. 📺 Screen Status

Indicators & Panel Lock

⏳ Delay Mode:

• After powering on, the chiller may have a 3-minute delay before starting.

• A blinking fan icon means it’s in delay mode.

🔒 Locked Panel:

• If there’s a lock icon on the screen, the panel is locked and settings can’t be changed.

🔓 Unlock the Panel:

• Press and hold the power button + down button ▼ at the same time to unlock.



Function Introduction

Install 1/3 HP Water Chiller with Bathtubs (with ports)

Install a 1/3 HP Water Chiller with a Bathtub (with Ports)

💧 Connection Instructions:

First hose: Connect the bottom inlet of the chiller to the bottom outlet of the bathtub.

Second hose: Connect the upper outlet of the chiller to the upper inlet of the bathtub.

💡 How It Works:
Water flows from the tub into the chiller through the bottom hose, passes through the pump and filter inside the chiller, and returns to the tub through the top hose — completing a full cooling cycle.

🛁 Tip:
We include an extra submersible pump, made specifically for standard home bathtubs.


How to Set Up a Water Chiller with Home Bathtubs (no ports)



🧰 Hose Setup

• Connect one hose (with quick connector) to the top outlet of the chiller. Place the other end directly into your tub.

• Connect the second hose to the bottom inlet of the chiller.

• Attach the other end of that hose to the submersible pump, and place the pump fully underwater inside your tub.



🔄 Water Flow Explained

• The submersible pump pulls water from the tub.

• Water enters the chiller through the inlet.

• Inside the unit, it gets filtered and cooled.

• Then it flows back into the tub through the outlet hose.

• This creates a continuous cold water circulation.



💡 Installation Tips

If the hose connected to the pump already has a male connector, cut off a small section of the hose to make it easier to fit onto the pump.

You can use a hair dryer to gently warm and soften the hose—this makes it much easier to attach.



✅ Note

Trimming the hose won’t affect your return or warranty service.





Troubleshooting

Please check if the machine is locked,The screen control will be auto. locked after 30 seconds without operation. To unlock the screen, long-press and hold the Power and Down buttons together for 5 seconds.

Please check all of the following:

1.The ambient temperature is too high.
Keep the ambient temperature below 35 degrees and ensure good ventilation.

2.The chiller is placed inside a closed cabinet.
Please place the chiller on an open, flat surface to ensure good ventilation.

3.The water volume exceeds the cooling capacity.
Reduce the water volume or replace with a chiller with a higher cooling capacity.

4.The water in the tub cannot cool down
Check if the water circulation is functioning properly.

Please check all of the following:

1.The water pump is not working properly and is not powered on.
Unplug the water pump and plug it back into the power outlet.

2.The water pipe is twisted.
A severely twisted water pipe can prevent water from flowing. Please ensure the pipe is adjusted for smooth flow.

3.The water circulation is small
Check the ice pod valve and ensure it is in the open position.

Manual

The Chiller is specifically designed to cool the temperature of any water up to 250L for cold plunges to the optimal level to maximize cold therapy benefits.

Its robust construction and user-friendly interface make it suitable for:

  • Home gyms & personal recovery setups
  • Pro athletes & training centers
  • Physical therapy & rehab clinics
  • Wellness retreats & spa environments
  • Research labs exploring cold therapy science

Whether you're recovering after a tough workout or building a daily wellness routine, the Plunge Chill Chiller delivers consistent performance and fast cooling, so you can stay refreshed, restored, and ready for more.

1. Power & Noise
✧Compressor: 1/3 HP, 600W
✧Noise Level: 39-45 dB (quieter than a refrigerator)

2. Temperature Range
✧Minimum Cooling: 42°F
✧Cooling Capacity: Chills 66 gallons down to 50°F about 8 hours from 75°F, to 45°F about 12 hours.

3. Physical Dimensions
✧Weight: 35 lbs
✧Size: 14.9" L × 11.8" W × 12.6" H

4. Rapid Ice-Free Cooling
✧Industrial-grade compressor cools water swiftly to therapeutic temperatures, eliminating the need for ice.

5. All-in-One Design
✧Built-in 24/7 water pump and mesh filter for continuous flow and debris removal (leaves, sand, impurities).

6. Insulated Hoses
✧Dual thermal-insulation hoses minimize heat exchange in hot environments, ensuring stable water temperature.

7. Set & Forget Convenience
✧Intuitive touchscreen for target temperature setting; auto-maintains desired coldness once achieved.

8. Easy Installation
✧2-step setup: Connect hoses and power on. Ready to use in 1 minute.

9. Low Maintenance
✧Self-cleaning filtration system reduces upkeep costs and extends water clarity for weeks.

10. Port Compatibility
✧The chiller comes pre-fitted with a standard 1/2 inch male thread adapter for effortless connection to our Ice Pod’s valves.

11. Power Usage
✧1/3 HP model with a working efficiency of 600W and uses the same
energy-efficient compressor technology found in household fridges and
freezers.
✧Power consumption depends on climate and usage, but on
average, expect to spend around $0.80–$1.50 USD per day in electricity —
that's around 20 times cheaper than buying ice daily.


12. Bathtub Adaptation
✧If using a submersible pump with standard bathtub, please remove the
external thread from the pipe or cut off part of the tube to ensure
proper connection.

  • 1 x Chiller Unit
  • 2 x Hoses with Insulation
  • 1 x Power Cable
  • 1 x Waterproof Tape
  • 1 x Manual Guide
  • 1 x Submersible pump

  • Set your ideal precise temperature via the touchscreen
  • The pump draws water to the chiller and cools to your set temperature
  • The cooled water is recirculated back into the tub
  • It automatically maintains your set temperature energy efficiently 24/7
  • Delay cooling to minimize energy usage
